| Battery | Deep cycle, lead acid battery, Trojan brand, imported |
| Motor | 6.3, 10, 12, 16.6 KW DC/AC |
| Controller | Curtis brand, series excited, imported /Zapi AC2 |
| Passenger capacity | 23 |
| Range (loaded) based on flat road at a speed of 20km/h (km)＊ | >70-80 depends on motor setup |
| Max. speed (km/h) | 45 |
| Minimum turning radius (m) | 6.5 |
| Max. climbing ability (loaded) | 15%/20 depends on motor setup |
| Max. loading weight | 1840kgs |
| Overall dimensions (mm) | 5950*1950*2170 |
| Ground Clearance (mm) | 165 |
| Body and Frame | |
| Frame | Welded steel framework with sand blasting+paint treatment |
| Body | Fibreglass |
| Roof | Fibreglass+aluminum frame |
| Windshield | Laminated glass |
| Large Seats: | Sponge + artificial leather, aluminum armrest |
| Floor | Bamboo + artificial leather |
| Electric system | |
| Lighting system and horn | Front: 2 Headlights (High beam and dipped headlight), 2 front turn signals, 2 fog lights; Back: 2 rear turn signals, 2 taillights(position light & brake light), 1 fog light, 1 reverse light),with DC-DC converter (converting from 48V to 12V) , horn. |
| Dashboard | Voltameter, ammeter, speedometer, turn signal indicator, headlight indicator, emergency switch, fog light switch; Headlight switch, turn signal switch, wiper switch, horn button; |
| Audio System | Radio and MP3 receiver with 6pcs speaker |
| Charger | China origin, input 110V-240V~50Hz-60Hz, output 72V, 25A , 2pcs |
| Steering and Suspension | |
| Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function, with hydraulic power assistant steering system |
| Brake system | Front disc brake and rear drum brake, with vacuum booster |
| Drive system | 5F+1R gear box, with clutch |
| Front Suspension system | Independent suspension, helix spring + shock absorberr |
| Rear Suspension system | rear plate spring + shock absorber |
| Wheel & Tyre | 215/70R15C-8PR, with steel wheel and wheel cap |
