| Battery | Deep cycle, lead acid battery, Trojan brand, imported |
| Motor Power | 3.8KW/5KW DC |
| Controller | Curtis brand, Separate/Series excited, imported |
| Passenger capacity | 4 |
| Range (loaded) based on flat road at a speed of 20km/h (km) | >60 |
| Max. speed(km/h) | 32 |
| Minimum turning radius (m) | 5.42 |
| Max. climbing ability | 20% |
| Max. loading weight | 360kgs |
| Overall dimensions (mm) | 3060x1410x1960 |
| Ground Clearance (mm) | 155 |
| Body and Frame | |
| Frame | Welded steel framework with sand blasting+paint treatment |
| Body | Fibreglass |
| Roof | FRP |
| Hard door | Steel frame+steel plate |
| Windshield | Laminated |
| Large Seats: | Sponge + artificial leather |
| Floor | Bamboo board+ rubber |
| Electric system | |
| Lighting system and horn | 2 headlights, 2 front turn signals, 2 rear turn signals and 2 rear brake lights, with DC-DC converter (converting from 48V to 12V), horn. |
| Dashboard meter | current meter, battery power meter, speedometer |
| Audio system | Tape player with radio (12v)(including 2 water-proof speakers, wired microphone) |
| Charger | input 110V-240V~50Hz-60Hz, output 48V, 25A |
| Steering and Suspension | |
| Steering system | Single-stage rack and pinion steering system, automatic rocker rocker compensating function |
| Brake system | 4-wheel hydraulic brake + foot activated parking brake |
| Drive mode | Rear axle two stage deceleration, motor direct driving |
| Front Suspension system | Independent suspension, helix spring + shock absorber |
| Rear Suspension system | rear plate spring + shock absorber |
| Wheel & Tyre | 225/55b12 10PR tire, 12X7 aluminum wheel |
