Battery |
8xT105(185Ah@5hr rate) |
Motor Power |
3.8KW Chinese motor |
Controller |
Curtis 1204 (275A@2minutes) |
Passenger capacity |
4 |
Range (loaded) based on flat road at a speed of 20km/h (km) |
>50 |
Max. speed(km/h) |
30 |
Minimum turning radius (m) |
4 |
Max. climbing ability |
20% |
Max. loading weight |
320kgs |
Overall dimensions (mm) |
3060x1400x1900 |
Ground Clearance (mm) |
155 |
Body and Frame |
|
Frame |
Welded steel framework with sand |
Body |
Fibreglass + Plastic |
Roof |
Fibreglass |
Windshield |
Laminated glass |
Large Seats: |
Sponge + artificial leather |
Floor |
Bamboo + artificial leather |
Electric system |
|
Lighting system and horn |
2 headlights, 2 front turn signals, 2 rear turn signals and 2 rear brake lights, with DC-DC converter (converting from 48V to 12V), horn. |
Police light system |
police light with siren and microphone |
Dashboard meter |
Digital meter |
Audio system |
Radio and MP3 receiver |
Charger |
China origin, input 110V-240V~50Hz-60Hz, output 48V, 22A onboard |
Steering and Suspension |
|
Steering system |
Single-stage rack and pinion steering system, automatic rocker compensating function |
Brake system |
Four wheel hydraulic drum brake+Hand brake |
Drive mode |
Rear axle two stage deceleration, motor direct driving |
Front Suspension system |
Independent suspension, helix spring + shock absorber |
Rear Suspension system |
rear plate spring + shock absorber |
Wheel & Tyre |
225/55R12C tire, 12X7 aluminum wheel |
