| Battery |
Deep cycle, lead acid battery, Trojan brand, imported |
| Motor Power |
3.8KW DC |
| Controller |
Curtis brand, Separate, imported |
| Passenger capacity |
4 |
| Range (loaded) based on flat road at a speed of 20km/h (km) |
>60 |
| Max. speed(km/h) |
40 |
| Minimum turning radius (m) |
5.42 |
| Max. climbing ability |
20% |
| Max. loading weight |
360kgs |
| Overall dimensions (mm) |
3060x1400x1900 |
| Ground Clearance (mm) |
155 |
| Body and Frame |
|
| Frame |
Welded steel framework with sand blasting+paint treatment |
| Body |
Fibreglass |
| Roof |
FRP |
| Windshield |
Laminated |
| Large Seats: |
Sponge + artificial leather |
| Floor |
Bamboo board+ rubber |
| Electric system |
|
| Lighting system and horn |
2 headlights, 2 front turn signals, 2 rear turn signals and 2 rear brake lights, with DC-DC converter (converting from 48V to 12V), horn. All lights are EEC approved |
| Dashboard meter |
current meter, battery power meter, speedometer |
| Audio system |
Tape player with radio (12v)(including 2 water-proof speakers, wired microphone) |
| Charger |
input 110V-240V~50Hz-60Hz, output 48V, 25A |
| Steering and Suspension |
|
| Steering system |
Single-stage rack and pinion steering system, automatic rocker rocker compensating function |
| Brake system |
4-wheel hydraulic brake + foot activated parking brake |
| Drive mode |
Rear axle two stage deceleration, motor direct driving |
| Front Suspension system |
Independent suspension, helix spring + shock absorber |
| Rear Suspension system |
rear plate spring + shock absorber |
| Wheel & Tyre |
225/55b12 10PR tire, 12X7 aluminum wheel |
