| Battery |
Deep cycle, lead acid battery, Trojan brand, imported |
| Motor Power |
5KW DC |
| Controller |
Curtis brand, Series excited, imported |
| Passenger capacity |
2 |
| Range (loaded) based on flat road at a speed of 20km/h (km) |
>80 |
| Max. speed(km/h) |
30 |
| Minimum turning radius (m) |
N/A |
| Max. climbing ability |
15% |
| Max. loading weight |
1000kgs |
| Overall dimensions (mm) |
4420X14600X1910 |
| Body and Frame |
|
| Frame |
Welded steel framework with sand blasting+paint treatment |
| Body |
FRP body |
| Roof |
Plastic |
| Cabin |
Steel frame + plastic door |
| Windshield |
Laminated glass |
| Large Seats: |
With backrest and headrest, sliding |
| Floor |
Anti-sliding ruber floor mat |
| Side rear view mirror |
\ |
| Electric system |
|
| Lighting system and horn |
2 combined front lights(headlight, turning light, position light), 2 front foglight, 2 taillight(turn signals and brake lights), with DC-DC converter (converting from 48V to 12V), horn. |
| Dashboard meter |
voltameter, ammeter, odometer, emergency switch; combined switch, meter indicator |
| Audio System |
Radio and MP3 adaptor, with 2 speakers |
| Wiper |
12V, 50W, single arm |
| Charger |
input 110V-240V~50Hz-60Hz, output 48V, 25A |
| Steering and Suspension |
|
| Steering system |
Single-stage rack and pinion steering system, automatic rocker |
| Brake system |
Four wheel hydraulic drum brake+ parking brake |
| Transmission system |
Rear axle two stage deceleration, motor direct driving |
| Front Suspension system |
plate spring + hydraulic shock absorber |
| Rear Suspension system |
integrated rear end, rear plate spring + hydrualic shock absorber |
| Wheel & Tyre |
4J*12 Steel wheel, wheel cap, 155R12C,8PR |
